Create a new Ingress resource as follows: Name: echo Namespace: sound-repeater The availability of Service echoserver-service can be checked using the following command, which should return 200 :

Question

Exhibit

Explanation

The user needs to create a Kubernetes Ingress resource named 'echo' in the 'sound-repeater' namespace, configured to route root path traffic to the 'echoserver-service' on port 80.

Approach. The user must type the following command into the web terminal to create the Ingress resource: kubectl create ingress echo --namespace sound-repeater --rule="/=echoserver-service:80"

Common mistakes.

• common_mistake. 1. Incorrect Namespace: Creating the Ingress in the default namespace or any other namespace (e.g., 'development' as seen in the exhibit) instead of 'sound-repeater' would result in failure, as the resource would not be found or validated correctly in the specified location.

1. Incorrect Service Name or Port: Misspelling echoserver-service or specifying an incorrect port (e.g., 8080 if 80 is expected) would prevent the Ingress from successfully routing traffic to the backend service, leading to connectivity issues or non-200 responses.
2. Missing or Incorrect Rule/Backend: Failing to specify a routing rule (--rule) or a default backend (--default-backend) would create an Ingress that does not direct any traffic to the echoserver-service, making it non-functional.
3. Syntax Errors: Any typos or incorrect kubectl command syntax would prevent the Ingress resource from being created successfully. If a YAML file is chosen instead, missing apiVersion, kind, or incorrect indentation/field names would also cause errors.
4. Forgetting pathType in YAML: When manually creating Ingress YAML for networking.k8s.io/v1, pathType (e.g., Prefix, Exact) is a mandatory field. A common mistake is to omit it, which would cause validation errors. (Note: kubectl create ingress handles this implicitly for simple rules like /).

Concept tested. The core concept being tested is the ability to create and configure Kubernetes Ingress resources to expose internal Services externally via HTTP/HTTPS routing. This includes understanding the Ingress object structure, specifying namespaces, defining routing rules (paths, backend services, and ports), and using kubectl commands for resource management within a Kubernetes cluster.
