Monitor and troubleshoot Windows Server environments

Question

You have an Azure virtual machine named VM1 that runs Windows Server. VM1 has boot diagnostics configured to use a managed storage account.
You are troubleshooting connectivity issue on VM1.
You need to run a PowerShell cmdlet on VM1 by using the Azure Serial Console.
Which four actions should you perform in sequence? To answer, move the appropriate actions from the list of actions to the answer area and arrange them in the correct order.

Exhibit

Explanation

The correct sequence of actions is:

From the Azure portal, configure the Boot diagnostics settings for VM1 to use a custom storage account.
From the Azure portal, open the Run command blade.
From the Serial console, run cmd.
From the Serial console, run ch -si 1 and sign in by using a local account.

Further details on using the serial console: To connect to the serial console, if you successfully connect, the prompt is SAC:>. Enter cmd to create a channel that has a CMD instance. Enter ch -si 1 or press the <esc><tab> shortcut keys to switch to the channel that's running the CMD instance. Press Enter, and then enter sign-in credentials with administrative permissions. After you've entered valid credentials, the CMD instance opens. To start a PowerShell instance, enter PowerShell in the CMD instance, and then press Enter. Reference: https://docs.microsoft.com/en-us/troubleshoot/azure/virtual-machines/serial-console-windows
