210-065 · Question #197
Refer to the exhibits. The screenshots show outputs from the xStatus of a Cisco TelePresence endpoint and the VCS registrations. What are the protocol and direction of the call, the called party…
The correct answer is B. h.323, outgoing, 5919*2345, 1152 Kb/s. The Cisco TelePresence xStatus command output provides real-time call details including protocol, direction, called party, and transmit bandwidth.
Question
Refer to the exhibits. The screenshots show outputs from the xStatus of a Cisco TelePresence endpoint and the VCS registrations. What are the protocol and direction of the call, the called party, and the transmit rate of the call?
Exhibit
Options
- Ah.323, incoming, 5919*2345, 1152 Kb/s
- Bh.323, outgoing, 5919*2345, 1152 Kb/s
- Ch.323, incoming, 5919*2345, 768 Kb/s
- Dsip, incoming, 5919*2345, 768 Kb/s
- Esip, outgoing, 5919*2345, 768 Kb/s
How the community answered
(29 responses)- A7% (2)
- B45% (13)
- C28% (8)
- D3% (1)
- E17% (5)
Why each option
The Cisco TelePresence xStatus command output provides real-time call details including protocol, direction, called party, and transmit bandwidth.
The xStatus call direction field shows the call is outgoing, not incoming, so this answer is incorrect despite the correct protocol and called party.
The xStatus output shows H.323 as the signaling protocol and outgoing as the call direction, with the called party identified as 5919*2345 using the asterisk separator standard in H.323 conference addressing. The transmit rate field in the xStatus output reports 1152 Kb/s, confirming the bandwidth allocated for the active call.
The transmit rate displayed in the xStatus output is 1152 Kb/s, not 768 Kb/s, making the bandwidth value incorrect.
The xStatus protocol field identifies the call as H.323, not SIP, and the direction is outgoing rather than incoming.
The xStatus protocol field identifies the call as H.323, not SIP, regardless of the other fields being partially correct.
Concept tested: Interpreting Cisco TelePresence xStatus call output
