What is the result of issuing the frame-relay map ip 192.168.1.2 202 broadcast command?

The correct answer is D. defines the DLCI that is used for all packets that are sent to the 192.168.1.2 IP address. The command 'frame-relay map ip 192.168.1.2 202 broadcast' creates a static mapping that tells the router: 'To reach IP address 192.168.1.2, use DLCI 202.' This is a destination-to-DLCI mapping - the IP address is the remote destination, and 202 is the local DLCI number to use wh

Implement Wide-Area Networks

Question

What is the result of issuing the frame-relay map ip 192.168.1.2 202 broadcast command?

Exhibit

Options

Adefines the destination IP address that is used in all broadcast packets on DCLI 202
Bdefines the source IP address that is used in all broadcast packets on DCLI 202
Cdefines the DLCI on which packets from the 192.168.1.2 IP address are received
Ddefines the DLCI that is used for all packets that are sent to the 192.168.1.2 IP address

How the community answered

(43 responses)

A
2% (1)
B
2% (1)
C
5% (2)
D
91% (39)

Explanation

The command 'frame-relay map ip 192.168.1.2 202 broadcast' creates a static mapping that tells the router: 'To reach IP address 192.168.1.2, use DLCI 202.' This is a destination-to-DLCI mapping - the IP address is the remote destination, and 202 is the local DLCI number to use when sending packets to that destination. The 'broadcast' keyword allows broadcast/multicast traffic (needed for routing protocols) to be replicated over this PVC. Option D correctly describes this: it defines the DLCI used for all packets sent to 192.168.1.2.

Topics

#Frame Relay#static mapping#DLCI#frame-relay map

Community Discussion

No community discussion yet for this question.
