The command show frame-relay map gives the following output: Serial 0 (up): ip 192.168.151.4 dlci 122, dynamic, broadcast, status defined, active Which statements represent what is shown? (Choose thre

Question

Exhibit

Options

• A192.168.151.4 represents the IP address of the remote router
• B192.168.151.4 represents the IP address of the local serial interface
• CDLCI 122 represents the interface of the remote serial interface
• DDLCI 122 represents the local number used to connect to the remote address
• Ebroadcast indicates that a dynamic routing protocol such as RIP v1 can send packets across this PVC
• Factive indicates that the ARP process is working

• A
  74% (28)
• B
  13% (5)
• C
  5% (2)
• F
  8% (3)

Explanation

Breaking down the output 'Serial 0 (up): ip 192.168.151.4 dlci 122, dynamic, broadcast, status defined, active': (A) is correct - the IP address 192.168.151.4 is the remote router's IP address that the local DLCI maps to. (B) is wrong - that is not the local interface's IP. (C) is wrong - DLCIs are locally significant; DLCI 122 does not represent a remote interface number. (D) is correct - DLCI 122 is the locally assigned number this router uses to identify the virtual circuit to that remote address. (E) is correct - the 'broadcast' keyword allows broadcast and multicast packets (including routing protocol updates like RIP) to be forwarded across the PVC. (F) is wrong - 'active' means the PVC is up and operational per LMI signaling, not specifically about ARP.
