Which type of LAN technology is being displayed in the diagram?

The correct answer is C. Mesh Topology. The diagram displays a mesh topology, where each device is connected to every other device in the network. This topology is characterized by the multiple connections each node has, ensuring there is no single point of failure and providing redundant paths for data transmission…

Submitted by eva_at· Apr 18, 2026Cybersecurity Foundations

Question

Exhibit

Options

AStar Topology
BSpine Leaf Topology
CMesh Topology
DBus Topology

How the community answered

(37 responses)

A
5% (2)
B
3% (1)
C
92% (34)

Explanation

The diagram displays a mesh topology, where each device is connected to every other device in the network. This topology is characterized by the multiple connections each node has, ensuring there is no single point of failure and providing redundant paths for data transmission, enhancing the reliability and resilience of the network. Mesh topology is one of the types of LAN technology that uses ethernet or Wi-Fi to connect devices.

Topics

#Network Topology#LAN Technology#Mesh Topology#Networking Fundamentals
