JN0-660 · Question #117
Click the Exhibit button. Customer A is complaining that routes advertised from the CE2 router are not being received on the CE1 router. The physical topology of the network is CE1-PE1-PE2- CE2. The…
The correct answer is B. Route targets are not properly configured. See the full explanation below for the reasoning.
Question
Click the Exhibit button. Customer A is complaining that routes advertised from the CE2 router are not being received on the CE1 router. The physical topology of the network is CE1-PE1-PE2- CE2. The CE1-PE1 subnet is 172.16.1.0/24. The CE2-PE2 subnet is 172.16.2.0/24. PE1's loopback is 192.168.3.1 and PE2's loopback is 192.168.4.1.Referring to the output in the exhibit, what is the problem?
Exhibit
Options
- ANo LSP exists between PE1 and PE2.
- BRoute targets are not properly configured.
- Cas-override is not configured in the VRFs.
- Dfamily inet-vpn is not configured on the PEs.
How the community answered
(35 responses)- A9% (3)
- B74% (26)
- C3% (1)
- D14% (5)
Community Discussion
No community discussion yet for this question.
