Juniper
JN0-660 · Question #112
Click the Exhibit button. In the exhibit, network 172.16.0.0/16 is redistributed into IS-IS in Area 49.0002. R1 must use R2 to access 172.16.0.0/16. All other traffic leaving Area 49.0001 must use…
The correct answer is A. Configure R1 to ignore the attached bit. C. Enable an L2 adjacency on the link between R1 and R2. D. Leak network 172.16.0.0/16 into L1 on R2. See the full explanation below for the reasoning.
Question
Click the Exhibit button. In the exhibit, network 172.16.0.0/16 is redistributed into IS-IS in Area 49.0002. R1 must use R2 to access 172.16.0.0/16. All other traffic leaving Area 49.0001 must use R4.Which three steps will accomplish this task? (Choose three.)
Exhibit
Options
- AConfigure R1 to ignore the attached bit.
- BDisable the attached bit on R4 in Area 49.0001.
- CEnable an L2 adjacency on the link between R1 and R2.
- DLeak network 172.16.0.0/16 into L1 on R2.
- ERedistribute a static default route into L1 on R4.
How the community answered
(21 responses)- A71% (15)
- B19% (4)
- E10% (2)
Community Discussion
No community discussion yet for this question.
