Given an existing Pod named nginx-pod running in the namespace test-system, fetch the service-account-name used and put the content in /candidate/KSC00124.txt Create a new Role named dev-test-role…

Question

Exhibits

Explanation

The user must execute a series of kubectl commands in the provided terminal to identify a pod's service account, create a Kubernetes Role with specific permissions, and bind that Role to the identified service account using a RoleBinding.

Approach. The correct interaction involves typing the following kubectl commands into the provided terminal environment. The exhibit images merely serve as context about the underlying Kubernetes node or shell environment, and the actual tasks require direct command-line input.

1. Fetch the service-account-name used by nginx-pod in test-system and put the content in /candidate/KSC00124.txt: To correctly identify the service account name, we need to inspect the nginx-pod. Kubernetes pods use the default service account if none is explicitly specified in their .spec.serviceAccountName field. The following commands handle both cases:

   SA_NAME=$(kubectl get pod nginx-pod -n test-system -o jsonpath='{.spec.serviceAccountName}')
   if [ -z "$SA_NAME" ]; then
       echo "default" > /candidate/KSC00124.txt
       SA_NAME="default" # Set for subsequent steps
   else
       echo "$SA_NAME" > /candidate/KSC00124.txt
   fi


   Explanation: kubectl get pod nginx-pod -n test-system -o jsonpath='{.spec.serviceAccountName}' extracts the explicit service account name. If this command returns an empty string (meaning no serviceAccountName is defined in the pod spec), the if condition handles it by writing default to the file and setting SA_NAME accordingly. Otherwise, the extracted name is saved. This ensures the correct, effective service account name is captured.

2. Create a new Role named dev-test-role in the namespace test-system, which can perform update operations on resources of type namespaces:

   kubectl create role dev-test-role -n test-system --verb=update --resource=namespaces


   Explanation: This imperative kubectl command directly creates a Role called dev-test-role within the test-system namespace. The --verb=update grants update permissions, and --resource=namespaces specifies that these permissions apply to namespaces resources.

3. Create a new RoleBinding named dev-test-role-binding, which binds the newly created Role to the Pod's ServiceAccount (found in the Nginx pod running in namespace test-system):

   kubectl create rolebinding dev-test-role-binding -n test-system --role=dev-test-role --serviceaccount=test-system:"$SA_NAME"


   Explanation: This imperative kubectl command creates a RoleBinding named dev-test-role-binding in the test-system namespace. It binds the previously created dev-test-role to the service account ($SA_NAME) that was identified in the first step. The test-system: prefix for the service account is important to specify its namespace scope correctly within the RoleBinding.

Common mistakes.

• common_mistake. A common mistake is failing to correctly identify the service account name, especially if the nginx-pod implicitly uses the default service account because serviceAccountName is not explicitly defined in its specification. Simply running kubectl get pod ... -o jsonpath='{.spec.serviceAccountName}' without handling an empty result would lead to an incorrect or missing service account name for the RoleBinding. Other mistakes include using ClusterRole or ClusterRoleBinding instead of Role and RoleBinding (which are namespace-scoped as required), specifying incorrect verbs (e.g., get instead of update) or resources (e.g., pods instead of namespaces) for the Role, or forgetting to specify the namespace (-n test-system) for the Role or RoleBinding. A critical error would be to attempt to interact with the vim editor or the Kubelet configuration shown in the exhibit images, as those are merely background context and not the interactive target for this specific question.

Concept tested. This question primarily tests Kubernetes Role-Based Access Control (RBAC) concepts, including the creation and management of Roles and RoleBindings, the understanding of ServiceAccounts (especially the implicit default service account), and the ability to use the kubectl command-line tool effectively for resource introspection (jsonpath) and creation. It also implicitly tests basic shell scripting knowledge for variable assignment and file redirection.
