Layer 3 Technologies

Question

Refer to the exhibit. Users in the branch network of 2001:db8:0:4::/64 report that they cannot access the Internet. Which command is issued in IPv6 router EIGRP 100 configuration mode to solve this issue?

Exhibit

Options

AIssue the eigrp stub command on R1.
BIssue the no eigrp stub command on R1.
CIssue the eigrp stub command on R2.
DIssue the no eigrp stub command on R2.

How the community answered

(49 responses)

A
6% (3)
B
78% (38)
C
2% (1)
D
14% (7)

Explanation

When a router is configured as an EIGRP stub, it advertises only its directly connected and summary routes, and it does NOT advertise routes learned from other EIGRP neighbors (such as an external default route toward the Internet). If R1 (the distribution/hub router that has Internet reachability) is incorrectly configured as an EIGRP stub, it will not propagate the default or external routes down to R2 and the branch network. Issuing 'no eigrp stub' on R1 removes the stub restriction, allowing R1 to advertise all routes - including the Internet-bound default route - so that branch hosts on 2001:db8:0:4::/64 can reach the Internet.

Topics

#EIGRP#IPv6 Routing#Stub Routers#Default Route

Community Discussion

No community discussion yet for this question.
