On the "Volunteer Analysis" chart sheet, drill down into the data to display the number of volunteer hours for each month.

Question

Exhibit

Explanation

Explanation: Drilling Down in an Excel Chart Sheet

Overall Goal

This task asks you to interact with a PivotChart (a chart linked to a PivotTable) on the "Volunteer Analysis" chart sheet. The chart currently displays volunteer hours at a summarized level - likely by year or quarter - and your goal is to drill down to reveal the underlying monthly breakdown. Drill-down is the correct approach because PivotCharts support data hierarchy navigation, letting you move from aggregated totals to finer detail without changing the source data.

Step-by-Step Breakdown

Step 1 - Navigate to the "Volunteer Analysis" chart sheet

Click the "Volunteer Analysis" tab at the bottom of the workbook. Chart sheets are standalone sheets containing only a chart, distinct from worksheet tabs. You must be on the correct sheet before interacting with the chart; drilling down on the wrong chart would modify unrelated data or produce an error.

Step 2 - Click on a data point or data series in the chart

Click directly on a bar, column, line point, or slice in the chart. This selects the specific element you want to drill into. Skipping this leaves nothing targeted - Excel won't know which level of the hierarchy to expand.

Step 3 - Right-click the selected element and choose "Drill Down"

Right-clicking opens the context menu. The Drill Down option tells the connected PivotTable to expand the hierarchy one level deeper - from the current grouping (e.g., Year) down to the next level (Month). This simultaneously updates both the PivotChart and any linked PivotTable. If you chose "Drill Up" instead, you would move to a higher summary level, which is the opposite of what's needed.

What Goes Wrong If Steps Are Skipped

Memory Tip

Think of the chart as a map zoom feature: you start at street-level overview (Year), then right-click and "Drill Down" to zoom into neighborhood detail (Month). You must click a location first before zooming - Excel works the same way.
