H12-811_V1.0 · Question #408
As shown in the figure, two hosts realize communication between TAs through single-arm routing. When the G0/0/1.2 sub-interface of RTA. receives the data frame sent by host B. to host A., RTA. will…
The correct answer is A. RTA. First delete VLAN tag 20, then add VLAN tag 10, and then send it out via G0/0/1.1 interface. See the full explanation below for the reasoning.
Question
As shown in the figure, two hosts realize communication between TAs through single-arm routing. When the G0/0/1.2 sub-interface of RTA. receives the data frame sent by host B. to host A., RTA. will execute which of the following Operation? ()
Exhibit
Options
- ARTA. First delete VLAN tag 20, then add VLAN tag 10, and then send it out via G0/0/1.1 interface
- BRTA. Forward the data frame directly through the G0/0/1.1 sub-interface
- CRTA. The data frame will be discarded
- DRTA. After deleting VLAN tag 20, it will be sent out by G0/0/1.1 interface
How the community answered
(67 responses)- A73% (49)
- B4% (3)
- C15% (10)
- D7% (5)
