As shown in the figure, FW_A establishes an IPSec tunnel with FW_B, and executes the display ike sa command on FW_A. The following information is obtained: < FW A > display ike sa Current ike sa…

Question

Exhibit

Options

• AThe route to the IKE peer is unreachable
• BThe ACLs at both ends do not overlap.
• CThe "remote gateway" of the local end does not match the "local address" of the opposite end.
• DInconsistent encryption algorithms

• A
  17% (11)
• B
  71% (46)
• C
  3% (2)
• D
  9% (6)

Explanation

Option B is correct because ACL mismatch between the two firewalls affects IPSec Phase 2 (traffic selector negotiation), not IKE Phase 1 (SA establishment). Since the output shows ike sa number: 0, Phase 1 never completed - and ACL non-overlap cannot cause Phase 1 to fail, only Phase 2.

The other three options all directly prevent IKE Phase 1 from completing: A (unreachable route) means IKE UDP packets never reach the peer; C (remote gateway / local address mismatch) means the IKE peers are trying to talk to the wrong endpoints, so they never handshake; D (mismatched encryption algorithms) causes the Phase 1 proposal exchange to fail since both sides must agree on cipher, hash, DH group, and lifetime.

Memory tip: Think of IKE Phase 1 as "Can we talk?" and Phase 2 as "What traffic do we protect?" - a zero IKE SA count means the peers never even started talking, so ACL rules (which govern what to protect in Phase 2) are irrelevant to the failure.
