CKS Question #64: Real Exam Question with Answer & Explanation

Question

Context: The kubeadm provisioned cluster was recently upgraded, leaving one node on a slightly older version due to workload compatibility concerns. Task: Upgrade the cluster node compute-0 to match the version of the control plane node. You must connect to the correct host. Failure to do so may result in a zero score. Initial connection: `ssh cks000034`. Use a command like `ssh compute-0` to connect to the compute node. Do not modify any running workloads in the cluster. Do not forget to exit from the compute node once you have completed your tasks.

Explanation

To upgrade the 'compute-0' node to match the control plane's Kubernetes version, the test-taker must first drain the node, SSH into it, upgrade kubeadm, run 'kubeadm upgrade node', upgrade kubelet and kubectl, restart kubelet, exit the node, and finally uncordon it.

Approach. The task is to upgrade a worker node ('compute-0') in a kubeadm provisioned cluster to match the control plane's Kubernetes version, ensuring no disruption to running workloads. This requires a precise sequence of kubectl and kubeadm commands executed in a terminal:

1. Determine the target Kubernetes version: From the initial administrative/control plane node (implied by starting with ssh cks000034 and having kubectl configured), identify the control plane's kubelet version. For example:

   K8S_VERSION=$(kubectl get nodes -o jsonpath='{.items[?(@.metadata.labels.node-role\.kubernetes\.io/control-plane)].status.nodeInfo.kubeletVersion}' | cut -d'v' -f2)
   # Example: K8S_VERSION would be '1.28.0' if control plane is v1.28.0


2. Drain the worker node compute-0 (on admin/control plane node): Evict all pods from compute-0 to prevent workload interruption, fulfilling the 'Do not modify any running workloads' constraint.

   kubectl drain compute-0 --ignore-daemonsets --delete-local-data


3. SSH into the worker node compute-0 (from admin/control plane node):

   ssh compute-0


4. Upgrade kubeadm on compute-0: Update the kubeadm package to the target version. (Assuming Debian/Ubuntu with apt for package management):

   sudo apt-get update
   sudo apt-get install -y kubeadm=${K8S_VERSION}-00 # E.g., kubeadm=1.28.0-00


5. Run kubeadm upgrade node on compute-0: This command updates static pods, certificates, and other cluster components managed by kubeadm on the node.

   sudo kubeadm upgrade node


6. Upgrade kubelet and kubectl on compute-0: Update the remaining Kubernetes packages to the target version.

   sudo apt-get install -y kubelet=${K8S_VERSION}-00 kubectl=${K8S_VERSION}-00 # E.g., kubelet=1.28.0-00 kubectl=1.28.0-00


7. Restart kubelet service on compute-0: This ensures the new kubelet binaries and configurations are loaded.

   sudo systemctl daemon-reload
   sudo systemctl restart kubelet


8. Exit from compute-0: As instructed, exit the worker node's SSH session.

   exit


9. Uncordon compute-0 (back on admin/control plane node): Mark compute-0 as schedulable again so it can receive new workloads.

   kubectl uncordon compute-0


10. Verify the upgrade (optional but highly recommended): Confirm that compute-0 now reports the correct Kubernetes version.

    kubectl get nodes


Common mistakes.

• common_mistake. Common mistakes include:

• Forgetting to drain and uncordon: Not draining the node (kubectl drain) before upgrade would violate the 'Do not modify any running workloads' constraint by abruptly terminating pods. Forgetting to uncordon (kubectl uncordon) after the upgrade would leave the node unschedulable, preventing new pods from being deployed on it.
• Incorrect package version: Not explicitly specifying the exact target version (e.g., kubeadm=1.28.0-00) during apt-get install (or yum install) might install a different or incompatible version, or even downgrade components.
• Incorrect command execution order or location: Running kubeadm upgrade node before kubeadm itself is updated, or attempting to upgrade kubelet/kubectl before kubeadm upgrade node could lead to inconsistent states. Also, some commands (kubectl drain, kubectl uncordon) must be run from the control plane/administrative machine, while others (kubeadm and package upgrades) must be run directly on the compute-0 node via SSH.
• Not restarting kubelet: After upgrading the kubelet binary, the service must be reloaded and restarted for the changes to take effect.
• Misinterpreting images as interactive: The provided static images are not interactive and should not be confused with hotspots, drag-and-drop elements, or configuration panels. Time spent trying to interact with them would be wasted.

Concept tested. Kubernetes cluster node lifecycle management, specifically the process of upgrading a worker node in a kubeadm provisioned cluster. This includes understanding the kubeadm upgrade workflow, proper node maintenance procedures (kubectl drain and kubectl uncordon), and Linux package management for Kubernetes components (kubeadm, kubelet, kubectl).
