Refer to the exhibit. In the DWDM network, a ring topology carries multiple services between two sites. Which option describes the employed protection design?

The correct answer is C. Client protection. In a DWDM ring topology carrying multiple services between two sites, client protection means the client-layer equipment at each end is responsible for detecting failures and switching to the alternate path around the ring.

Designing Network Infrastructure

Question

Refer to the exhibit. In the DWDM network, a ring topology carries multiple services between two sites. Which option describes the employed protection design?

Exhibit

352-001 question #289 exhibit

Options

  • AY-cable protection
  • BSplitter protection
  • CClient protection
  • DUDLD
  • EFEC protection

How the community answered

(33 responses)
  • A
    3% (1)
  • B
    6% (2)
  • C
    76% (25)
  • D
    3% (1)
  • E
    12% (4)

Why each option

In a DWDM ring topology carrying multiple services between two sites, client protection means the client-layer equipment at each end is responsible for detecting failures and switching to the alternate path around the ring.

AY-cable protection

Y-cable protection uses a physical Y-shaped splitter to duplicate the transmit signal to two line cards simultaneously, which is a single-node point-to-point redundancy scheme and is not applicable to a ring topology serving multiple services.

BSplitter protection

Splitter protection uses an optical power splitter to broadcast the same signal over two separate paths at once, typically applied in point-to-point or hub-and-spoke architectures rather than ring topologies serving multiple services between two sites.

CClient protectionCorrect

Client protection delegates failure detection and path switchover to the client devices (routers or switches) rather than to the DWDM optical transport layer. In a ring topology between two sites, each client can reach the remote site via two diverse paths around the ring; when one path fails, the client equipment independently switches its traffic to the other path. This model is appropriate for multi-service rings because each client manages its own protection without requiring the DWDM layer to coordinate protection switching for every wavelength or service.

DUDLD

UDLD is a Cisco Layer 2 protocol that detects unidirectional Ethernet link failures; it is not a DWDM optical protection or switching mechanism.

EFEC protection

FEC (Forward Error Correction) is an optical modulation technique that corrects bit errors to improve signal quality over long spans; it does not provide path redundancy or protection switching in a ring topology.

Concept tested: DWDM ring client-layer protection design

Source: https://www.cisco.com/c/en/us/td/docs/optical/dwdm/configuration/guide/b_dwdm_config_guide/b_dwdm_config_guide_chapter_0101.html

Topics

#DWDM#client protection#optical ring topology#protection switching
