300-415 · Question #450

Refer to the exhibit. A WAN Edge device cannot connect to SD-WAN Validator; however, can ping it. Which action resolves the issue?

The correct answer is C. Install the correct root certificate on WAN Edge. If a WAN Edge can ping the SD-WAN Validator but cannot establish a control connection, the most common issue is a problem with certificate-based authentication.

WAN Edge Router Deployment

Question

Refer to the exhibit. A WAN Edge device cannot connect to SD-WAN Validator; however, can ping it. Which action resolves the issue?

Exhibit

300-415 question #450 exhibit

Options

  • AVerify that the SD-WAN Validator IP address is correct.
  • BModify the system IP on WAN Edge.
  • CInstall the correct root certificate on WAN Edge.
  • DSwitch the peer protocol from DTLS to TLS.

How the community answered

(40 responses)
  • A
    3% (1)
  • B
    5% (2)
  • C
    83% (33)
  • D
    10% (4)

Why each option

If a WAN Edge can ping the SD-WAN Validator but cannot establish a control connection, the most common issue is a problem with certificate-based authentication.

AVerify that the SD-WAN Validator IP address is correct.

The ability to ping the SD-WAN Validator confirms that its IP address is correct and reachable from the WAN Edge, ruling out an incorrect IP as the root cause.

BModify the system IP on WAN Edge.

Modifying the system IP on the WAN Edge device is a logical identifier change and would not directly resolve a failure to establish a secure control connection when basic network reachability (ping) is confirmed.

CInstall the correct root certificate on WAN Edge.Correct

In Cisco SD-WAN, control plane connections (DTLS/TLS) between WAN Edges and the SD-WAN Validator (vBond) are secured using certificates; if the WAN Edge lacks the correct root certificate to validate the Validator's certificate, the secure connection will fail despite basic IP connectivity.

DSwitch the peer protocol from DTLS to TLS.

Switching the peer protocol between DTLS and TLS does not address the underlying issue of certificate validation, as both protocols rely on properly installed and trusted certificates for secure communication.

Concept tested: Cisco SD-WAN WAN Edge onboarding and certificate requirements

Source: https://www.cisco.com/c/en/us/td/docs/routers/sdwan/configuration/sdwan-xe-gs-cr-book/sdwan-deploy-devices.html

Topics

#SD-WAN Troubleshooting#WAN Edge Enrollment#Certificates#Control Plane
