300-415 · Question #172
300-415 Question #172: Real Exam Question with Answer & Explanation
The correct answer is D: Reconfigure the system-ip parameter on vSmart to 11.1.1.2.. The primary issue preventing vManage and vSmart from connecting to vBond is the duplicate 'system-ip' address shared between vManage and vSmart.
Controller Deployment
Question
Refer to the exhibit. vManage and vSmart have an issue establishing a connection to vBond. Which configuration resolves the issue?
vManage
system
system-ip 10.11.11.1
host-name vManage
site-id 1
clock timezone Europe/London
vbond 11.1.1.3
organization-name Cisco.com
Vpn 0
interface eth1
Ip address 11.1.1.24
No shut
Tunnel-interface
Allow-service all
Ip route 0.0.0.0/0 11.1.1.254
vSmart
system
system-ip 10.11.11.1
host-name vSmart
site-id 1
clock timezone Europe/Rome
vbond 11.1.1.3
organization-name Cisco.com
Vpn 0
interface eth1
Ip address 11.1.1.2/24
No shut
Tunnel-interface
Allow-service all
Ip route 0.0.0.0/0 11.1.1.254
vBond
system
system-ip 10.11.11.3
host-name vManage
site-id 1
clock timezone Europe/London
vbond 11.1.1.1 local
organization-name Cisco.com
Vpn 0
interface ge0/0
Ip address 11.1.1.3/28
No shut
Tunnel-interface
Encapsulation ipsec
Allow-service all
Ip route 0.0.0.0/0 11.1.1.254
Options
- AConfigure the tunnel interface on all three controllers with a color of transport.
- BChange the timezone on the vSmart to Europe/London.
- CConfigure the (11.1.1.X/24) IP addresses on the eth1 interfaces on vManage and vSmart.
- DReconfigure the system-ip parameter on vSmart to 11.1.1.2.
Explanation
The primary issue preventing vManage and vSmart from connecting to vBond is the duplicate 'system-ip' address shared between vManage and vSmart.
Common mistakes.
- A. Controllers' VPN 0 interfaces establish connectivity but do not typically have 'tunnel interface' configurations with a 'color of transport' in the same way WAN Edge routers do.
- B. While timezone mismatches can sometimes cause issues with certificate validation, the most direct and severe problem here is the duplicate system-ip address, which fundamentally breaks controller identification and communication.
- C. The IP addresses on the eth1 interfaces are already configured and appear to be valid within their respective subnets, so configuring them again would not resolve the duplicate system-ip issue.
Concept tested. SD-WAN controller unique system-IP requirement
Topics
#SD-WAN Control Plane#Controller Configuration#System IP#vBond Connectivity
