300-410 · Question #14

Which command allows traffic to load-balance in an MPLS Layer 3 VPN configuration?

The correct answer is D. Maximum-paths 2. To enable load balancing for MPLS Layer 3 VPN traffic, the maximum-paths command is used to specify the number of equal-cost paths a router can install in the routing table.

VPN Technologies

Question

Which command allows traffic to load-balance in an MPLS Layer 3 VPN configuration?

Exhibit

300-410 question #14 exhibit

Options

  • AMulti-paths eibgp 2
  • BMaximum-paths ibgp 2
  • CMulti-paths 2
  • DMaximum-paths 2

How the community answered

(46 responses)
  • A
    2% (1)
  • B
    2% (1)
  • C
    9% (4)
  • D
    87% (40)

Why each option

To enable load balancing for MPLS Layer 3 VPN traffic, the `maximum-paths` command is used to specify the number of equal-cost paths a router can install in the routing table.

AMulti-paths eibgp 2

The `multi-paths` command is not a standard BGP command for controlling the number of installed paths for load balancing.

BMaximum-paths ibgp 2

While `maximum-paths ibgp 2` is valid for iBGP paths, `maximum-paths 2` is the more general command for all BGP paths, which applies broadly to MPLS L3 VPN scenarios where both iBGP and eBGP paths might be considered.

CMulti-paths 2

The `multi-paths` command is not a valid or commonly used command for configuring path load balancing in Cisco IOS routing.

DMaximum-paths 2Correct

The `maximum-paths` command configures the maximum number of equal-cost paths that any routing protocol can install into the IP routing table, thereby enabling load balancing. In MPLS L3 VPNs, this allows BGP to install multiple paths for a VPN prefix, facilitating traffic distribution across the network infrastructure.

Concept tested: BGP equal-cost multi-path (ECMP) load balancing

Source: https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/iproute_bgp/configuration/xe-16/irg-xe-16-book/bgp-cfg-load-balance.html

Topics

#MPLS L3 VPN#Load Balancing#BGP#Routing Configuration
