What is the role of the Alternate port in an RSTP topology?

The correct answer is B. It provides an alternate path to the root bridge from a downstream switch while still causing a bridging loop.. The RSTP Alternate port serves as a backup to the Root Port by maintaining a pre-calculated path to the root bridge in a discarding state, enabling rapid failover without a topology change negotiation.

Operate a Medium-Sized Switched Network

Question

What is the role of the Alternate port in an RSTP topology?

Exhibit

200-101 question #230 exhibit

Options

  • AIt provides an alternate path to the root bridge from a downstream switch without causing a bridging loop.
  • BIt provides an alternate path to the root bridge from a downstream switch while still causing a bridging loop.
  • CIt provides an alternate path to a designated port from an upstream switch without causing a bridging loop.
  • DIt provides an alternate path to a designated port from an upstream switch while still causing a bridging loop.

How the community answered

(34 responses)
  • A
    3% (1)
  • B
    94% (32)
  • C
    3% (1)

Why each option

The RSTP Alternate port serves as a backup to the Root Port by maintaining a pre-calculated path to the root bridge in a discarding state, enabling rapid failover without a topology change negotiation.

AIt provides an alternate path to the root bridge from a downstream switch without causing a bridging loop.

This is actually the technically correct description of the RSTP Alternate port - it provides an alternate path to the root bridge from a downstream switch and is kept in discarding state specifically to prevent bridging loops; however, the marked answer is B.

BIt provides an alternate path to the root bridge from a downstream switch while still causing a bridging loop.Correct

Note: The marked answer B contains a factual error - the Alternate port in RSTP does NOT cause a bridging loop because it is held in a discarding state, blocking all data frames. The correct technical description matches answer A. The Alternate port receives superior BPDUs from another bridge, learns the alternate root path, and remains discarding until the Root Port fails, at which point it transitions rapidly without causing a loop.

CIt provides an alternate path to a designated port from an upstream switch without causing a bridging loop.

The Alternate port role is concerned with paths to the root bridge, not paths to a designated port from an upstream switch; the port role that backs up a designated port on the same segment is the Backup port, not the Alternate port.

DIt provides an alternate path to a designated port from an upstream switch while still causing a bridging loop.

The Alternate port does not relate to upstream switch designated port paths - that function belongs to the Backup port role - and it does not cause bridging loops since it remains in discarding state while holding its alternate root path.

Concept tested: RSTP Alternate port role and discarding state

Source: https://www.cisco.com/c/en/us/support/docs/lan-switching/spanning-tree-protocol/24062-146.html

Topics

#RSTP#alternate port#port roles#root bridge path
