156-315.71 · Question #167
You are preparing a lab for a ClusterXL environment, with the following topology: Vip internal cluster IP = 172.16.10.1; Vip external cluster IP = 192.168.10.3 Cluster Member 1: four NICs, three…
The correct answer is B. There is no problem with this configuration. It is correct. See the full explanation below for the reasoning.
Question
You are preparing a lab for a ClusterXL environment, with the following topology:
Vip internal cluster IP = 172.16.10.1; Vip external cluster IP = 192.168.10.3 Cluster Member 1: four NICs, three enabled: qfeO: 192.168.10.1/24, qfel:
10.10.10.1/24, qfe2:
172.16.10.1/24 Cluster Member 2: five NICs, three enabled; hmeO: 192.168.10.2/24, ethi:
10.10.10.2/24, eth2:
172.16.10.2/24 Member Network tab on internal-cluster interface: is 10.10.10.0, 255.255.255.0 SmartCenter Pro Server: 172.16.10.3 External interfaces 192.168.10.1 and 192.168.10.2 connect to a Virtual Local Area Network (VLAN) switch. The upstream router connects to the same VLAN switch. Internal interfaces 10.10.10.1 and 10.10.10.2 connect to a hub. There is no other machine in the 10.10.10.0 network. 172.19.10.0 is the synchronization network. What is the problem with this configuration? Check Point 156-315.71 Exam
Exhibits
Options
- AThe SmartCenter Pro Server cannot be in the synchronization network.
- BThere is no problem with this configuration. It is correct.
- CMembers do not have the same number of NICs.
- DThe internal network does not have a third cluster member.
- ECluster members cannot use the VLAN switch. They must use hubs.
How the community answered
(26 responses)- B85% (22)
- C4% (1)
- D8% (2)
- E4% (1)
