The nmon output below illustrates typical load when the hosted application is running at peak times. What can be observed from the output?

In IBM Power Systems LPAR environments, CPU entitlement defines the guaranteed processor capacity assigned to a partition. When nmon shows that peak workload utilization is significantly lower than the entitled CPU value, the partition holds more guaranteed capacity than it ever consumes, wasting resources that could be redistributed to other partitions on the system.

Virtual processor allocation being too low would appear as high run-queue depth or CPU wait times under load, not as consistent underutilization of entitled capacity.

Enabling SMT4 increases thread-level parallelism per core and would only help if CPUs were already saturated and threads were the bottleneck, not when entitlement far exceeds actual usage.

Processor folding dynamically deactivates logical processors when demand is low to conserve power, but it does not restrict access to entitled capacity and would not be shown as over-allocation in nmon.
